Phenolic Resin Piston And Rod Guide Ring Hydraulic Piston Seals Wear Ring FR Type

Brand Name : DZK

Model Number : 9.5MM*2.5MM

Place of Origin : CHINA

MOQ : 1PCS

Price : USD0.10-10.00/Pcs

Payment Terms : T/T, L/C

Supply Ability : 1000000 PCS /MONTH

Delivery Time : 1 Day if goods in stock. 7-15 Days if goods out of stock with molding.

Packaging Details : 10PCS/BAG

Size : 9.5MM*2.5MM

Temperature Range : -50 to +120 ° C

Color : Brown Or Black

Pressure Range : ＜60Mpa

Application : Piston&Rod

Shape : Round

Material : Phenolic Resin

Contact Now

FR Type Piston And Rod Guide Ring,Hydraulic Piston Seals Wear Ring,Phenolic Resin C/S 2.5mm ,Width 9.5mm

1. Product Description:

FR Guide ring is an open type, which is easy to install. Good abrasion resistance, suitable for the Hydraulic cylinder piston and rod.

Phenolic Resin Piston And Rod Guide Ring Hydraulic Piston Seals Wear Ring FR Type

2.APPLICATION:

Raw Material	Phenolic Resin
Pressure	＜60Mpa
Temperature Range	-50 to +120 ° C
Speed	≤0.5m/s
Type	Inclined Incision
Color	Brown Or Black
Use Part	Piston&Rod

3.SPECIFICATION:

t	H
2.5MM	9.5MM
2.5MM	9.7MM
2.5MM	14.8MM
2.5MM	19.7MM
2.5MM	24.7MM
2.5MM	30MM
2.5MM	40MM

4.Delivery & Payment Term:

Date Of Delivery:

1-2 work days if in stock.

7-10 work days, if goods out of stock Urgent shipment air freight.

Customized product delivery period negotiation..

Payment Term:

30% T/T in advance and 70% balance paid before shipment.

Western Union, Cash, T/T ,Bank, PayPaI

others for discussion
